Frontend-to-backend trace propagation ¶

By default, Faro collects browser-side traces but they're not connected to your backend spans in Tempo. With trace propagation, you get end-to-end visibility: a single trace that follows a user action from the browser through your backend services.

A few applications on Nais use this today (dp-saksbehandling-frontend, dp-brukerdialog-frontend, dp-mine-dagpenger-frontend). It's quick to set up and makes debugging cross-service issues far easier.

How it works ¶

sequenceDiagram
    participant Browser
    participant Backend
    participant Tempo

    Browser->>Backend: GET /api/data (traceparent: 00-abc123...)
    Backend->>Backend: Process request (child span)
    Backend->>Tempo: Export backend spans
    Browser->>Tempo: Export browser spans
    Note over Tempo: Same trace ID → linked

What you need ¶

Configure trace propagation in Faro ¶

Add propagateTraceHeaderCorsUrls to your TracingInstrumentation config. This tells Faro which URLs should receive the traceparent header:

import { getWebInstrumentations, initializeFaro } from '@grafana/faro-web-sdk';
import { TracingInstrumentation } from '@grafana/faro-web-tracing';

initializeFaro({
  url: '...', // collector endpoint
  app: { name: 'my-app' },
  instrumentations: [
    ...getWebInstrumentations(),
    new TracingInstrumentation({
      instrumentationOptions: {
        propagateTraceHeaderCorsUrls: [
          /https:\/\/my-backend\.nav\.no\/.*/,
        ],
      },
    }),
  ],
});

Use a regex or string that matches your backend API URLs. You can list multiple patterns:

propagateTraceHeaderCorsUrls: [
  /https:\/\/my-backend\.test-nais\.cloud\.nais\.io\/.*/,
],

If you build URLs from environment variables, escape them to prevent ReDoS:

function escapeRegExp(str: string): string {
  return str.replace(/[.*+?^${}()|[\]\\]/g, '\\$&');
}

propagateTraceHeaderCorsUrls: [
  new RegExp(`${escapeRegExp(apiUrl)}/.*`),
],

Configure CORS on your backend ¶

Your backend must allow the traceparent header in CORS responses. Without this, the browser blocks the header and trace propagation silently fails.

Add traceparent to Access-Control-Allow-Headers:

Access-Control-Allow-Headers: Content-Type, traceparent

If you also use tracestate (for vendor-specific trace context), allow that too:

Access-Control-Allow-Headers: Content-Type, traceparent, tracestate

Optional: Backend server-timing header ¶

To correlate backend responses back to the frontend trace, your backend can send a server-timing header containing the trace context. This lets Grafana link the response back to the backend span.

In a Next.js middleware:

// middleware.ts
import { NextRequest, NextResponse } from 'next/server';
import { trace } from '@opentelemetry/api';

export function middleware(request: NextRequest) {
  const response = NextResponse.next();
  const span = trace.getActiveSpan();

  if (span) {
    const { traceId, spanId } = span.spanContext();
    response.headers.set(
      'server-timing',
      `traceparent;desc="00-${traceId}-${spanId}-01"`,
    );
  }

  return response;
}

Verify it works ¶

Related ¶
